Littelfuse, Inc. announced the launch of its TPSMB Asymmetrical TVS Diode Series, the first-to-market asymmetrical transient voltage suppression (TVS) diode specifically designed for the protection of Silicon Carbide (SiC) MOSFET gate drivers in automotive applications.
This innovative product addresses the increasing demand for reliable overvoltage protection in next-generation electric vehicle (EV) systems, delivering a compact, single-component solution that replaces multiple Zener diodes or TVS components traditionally used for gate driver protection. View the video.
The TPSMB Asymmetrical TVS Diode Series provides superior protection for SiC MOSFET gate drivers, which are prone to overvoltage events due to faster switching speeds compared to traditional silicon-based MOSFETs or IGBTs. The unique asymmetrical design of the TPSMB Series supports SiC MOSFETs’ differing positive and negative gate driver voltage ratings, ensuring enhanced performance in a variety of demanding automotive power applications where SiC MOSFETs are used, including:
- Onboard chargers (OBCs)
- EV traction Inverters
- I/O interfaces
- Vcc buses
These applications demand high-performance overvoltage protection (OVP) for SiC MOSFET gate drivers to ensure optimal performance, longevity, and efficiency.
Charlie Cai, Director of Product Management, Protection Business, Littelfuse, emphasizes the value this product brings to automotive engineers: “The TPSMB Asymmetrical TVS Diode Series offers an innovative solution for SiC MOSFET gate driver protection, eliminating the need for multiple components and simplifying the design process for engineers. Its compact, reliable design ensures that critical automotive power systems are safeguarded against overvoltage events, supporting the continued advancement of electric vehicles and other high-performance applications.”
The TPSMB Asymmetrical Series Surface-Mount TVS Diode offers the following key features and benefits:
- A Single-Component SiC MOSFET Gate Driver Protection: Eliminates the need for multiple Zener or TVS diodes, streamlining design and reducing component count.
- Asymmetrical Gate Driver Voltage Protection: Designed to protect SiC MOSFET gate drivers, which require different negative and positive voltage ratings.
- Compact Design: Available in a DO-214AA (SMB J-Bend) package, the series is ideal for space-constrained automotive designs.
- Automotive-Grade Quality: AEC-Q101-qualified, ensuring the highest reliability for automotive applications.
- High Power Dissipation: 600W peak pulse power dissipation (10×1000μs waveform) offers robust protection against transient overvoltage events.
- Low Clamping Voltage: VC < 10 V @ 30 A (8/20 µs) for optimal negative gate drive protection.
- Wide Frequency Stability: Stable capacitance across a wide operating frequency range, up to 2 MHz, making it ideal for SiC MOSFET applications.
- Compatible with Leading SiC MOSFETs: Suited for use with Littelfuse and other market-leading automotive SiC MOSFETs.
Original – Littelfuse
-
Littelfuse, Inc. announced the release of the IXTN400N20X4 and IXTN500N20X4 Ultra Junction X4-Class Power MOSFETs.
The new devices expand upon the current 200 V X4-Class Ultra Junction MOSFETs, featuring some of the lowest on-state resistances available. The high current ratings of these MOSFETs allow designers to replace multiple low-current rated devices connected in parallel, streamlining the design process and enhancing both reliability and power density in applications. Additionally, the screw-mounted terminals of the SOT-227B package enable rugged and stable mounting.
These new 200 V MOSFETs deliver the lowest on-state resistances, enhancing and complementing the existing Littelfuse X4-Class Ultra Junction family portfolio. Compared to the existing state-of-the-art X4-Class MOSFET solutions, these MOSFETs offer up to ~2x higher current ratings and RDS(on) values up to ~63% lower.
The new MOSFETs are ideal for a range of low-voltage power applications where minimizing on-state losses is essential, including:
- Battery Energy Storage Systems (BESS),
- Battery chargers,
- Battery formation,
- DC/battery load switch, and
- Power supplies.
“The new devices will allow designers to replace multiple low-current rated devices, connected in parallel, with a single device solution,” said Sachin Shridhar Paradkar, Global Product Marketing Engineer at Littelfuse. “This unique solution simplifies gate driver design, improves reliability, improves power density and PCB space utilization.”
The Ultra Junction X4-Class Power MOSFET offers the following key performance benefits:
- Low conduction losses
- Minimized parallel connection effort
- Simplified driver design with minimal driver losses
- Simplified thermal design
- Increased power density
A MOSFET with low on-state resistance (RDS(on)) is the ideal choice in applications where minimal on-state losses are crucial. It significantly reduces the power dissipation during operation, leading to lower conduction losses, higher efficiency, and less heat generation. This makes it perfect for power-sensitive applications such as power supplies, motor drivers, and battery-operated devices where maintaining high efficiency and thermal management is crucial.
Performance Specifications
Performance Specs IXTN500N20X4 IXTN400N20X4 Package Aluminum-nitride ceramic-based isolated SOT-227B On-state resistance RDS(on) = 1.99 mΩ @ Tvj = 25°C RDS(on) = 3 mΩ @ Tvj = 25°C High nominal current rating 500 A @ TC = 25°C 340 A @ TC = 25°C Gate charge Qg = 535 nC Qg = 348 nC Thermal resistance RthJC = 0.13 K/W RthJC = 0.18 K/W Original – Littelfuse
-
Littelfuse, Inc. reported financial results for the third quarter ended September 28, 2024:
- Net sales of $567 million were down 7% versus the prior year period and organically
- GAAP diluted EPS was $2.32 and adjusted diluted EPS was $2.71
- Cash flow from operations was $80 million and free cash flow was $65 million
“In the third quarter, our global teams delivered strong execution and drove sales and earnings above our expectations,” said Dave Heinzmann, Littelfuse President and Chief Executive Officer. “While we see soft end market conditions extending into the fourth quarter, we remain focused on driving operational excellence while serving our global customer base and delivering meaningful new business wins. Our proven growth strategy, diversification efforts and strong technology capabilities position us to deliver top tier long-term stakeholder value.”
Based on current market conditions, for the fourth quarter the company expects Net sales in the range of $510 – $540 million, adjusted diluted EPS in the range of $1.90 – $2.10 and an adjusted effective tax rate of approximately 14%.
Original – Littelfuse
-
Littelfuse, Inc. announced the SMFA Asymmetrical Series Surface-Mount TVS Diode, the first-to-market asymmetrical TVS solution specifically designed to protect Silicon Carbide (SiC) MOSFET gates from overvoltage events. As SiC MOSFETs become increasingly popular due to their faster switching speeds and superior efficiency compared to traditional Silicon MOSFETs and IGBTs, the need for robust gate protection has never been greater. The SMFA Asymmetrical Series offers an innovative, single-component solution that significantly enhances circuit reliability while simplifying design.
The SMFA Asymmetrical Series is the only TVS diode on the market engineered specifically for the unique gate protection requirements of SiC MOSFETs. Unlike traditional solutions that require multiple Zener or TVS diodes, the SMFA Series effectively protects against ringing and overshoot phenomena in gate drive circuits using a single component, saving valuable PCB space and reducing the complexity of circuit designs.
The SMFA Asymmetrical Series Surface-Mount TVS Diode offers the following key features and benefits:
- Asymmetrical Design: The SMFA Series is tailored to the specific negative and positive gate voltage ratings of SiC MOSFETs, ensuring precise and reliable protection.
- Single-Component Solution: Replaces multiple Zener and TVS diodes, reducing the number of components and simplifying circuit layout.
- Space Efficiency: By combining multiple protection functions into one component, the SMFA Series minimizes PCB space usage, allowing for more compact and efficient designs.
- Compatibility: The SMFA Asymmetrical Series is compatible with all available Littelfuse and other leading SiC MOSFETs, making it a versatile solution for various applications.
“The SMFA Asymmetric TVS Diodes protect valuable SiC MOSFETs from gate failures using a single component solution that easily replaces multiple Zener and TVS diodes,” said Ben Huang, Director of Product Marketing at Littelfuse. “This unique solution also saves valuable PCB space while reducing the number of components required.”
The SMFA Asymmetrical Series is ideal for a variety of demanding applications where SiC MOSFETs are used, including:
- AI / Data Center Server Power Supplies: Enhances the reliability and efficiency of critical power supplies in high-performance computing environments.
- High-Efficiency Electric Vehicle Infrastructure (EVI) Power Systems: Provides robust gate protection in EV charging stations and related power systems, ensuring longevity and performance.
- High-Reliability Semiconductor/Industrial Equipment Power Supplies: Protects essential power supplies in industrial and semiconductor manufacturing environments, where reliability and uptime are paramount.
Original – Littelfuse
-
Littelfuse, Inc. announced the launch of the IX4341 and IX4342 dual 5 ampere low-side MOSFET gate drivers. These gate drivers are specifically designed for driving MOSFETs and complete the existing IX434x driver series by adding the remaining two logic input versions. The IX434x series now consists of dual non-inverting, dual inverting, and non-inverting and inverting input versions, providing customers with a comprehensive range of options.
The IX4341 and IX4342 drivers’ short propagation delay times of 16 nanoseconds and brief rise and fall times of 7 nanoseconds make them ideal for high-frequency applications. Additionally, for higher current requirements, electronics designers can parallel the two channels of the IX4340 and IX4341 devices to form a single 10 A driver, providing flexibility and scalability.
A notable feature of the IX434x drivers is their compatibility with TTL and CMOS logic inputs, enabling direct interfacing with most controllers. Furthermore, each output has an independent ENABLE function and under-voltage lockout circuitry (UVLO) to ensure reliable and safe operation. In case of eventual insufficient supply voltage, the gate driver output is asserted low, turning the external power device off.
The IX4341 and IX4342 dual 5 A low-side gate drivers find applications in various markets, including:
- general industrial and electrical equipment,
- appliances,
- building solutions,
- data centers,
- energy storage, and
- renewable energy.
These low-side MOSFET gate drivers are ideally suited for numerous industrial applications such as:
- switch-mode power supplies,
- DC-DC converters,
- motor controllers, and
- power converters.
The IX434x devices are available in standard 8-pin SOIC, thermally enhanced 8-pin SOIC, and 3×3 mm² MSOP packages, offering customers a range of options to suit their specific needs.
“This new series of dual five-ampere low-side gate drivers simplify circuit design with its high level of integration and compatibility with various logic input versions,” said June Zhang, Product Manager, Integrated Circuits Division, Semiconductor Business Unit, at Littelfuse. “With these drivers, customers can expect enhanced performance and protection for their power devices.”
The IX434x dual 5 A low-side gate drivers find applications in various industries, including general industrial and electrical equipment, appliances, building solutions, data centers, energy storage, and renewable energy.
They serve as a direct drop-in alternative to similar available drivers, providing customers with industry-standard options to meet their supply demands.
Original – Littelfuse
-
Littelfuse, Inc. reported financial results for the second quarter ended June 29, 2024:
- Net sales of $558 million were down 9% versus the prior year period, and down 8% organically
- GAAP diluted EPS was $1.82 and adjusted diluted EPS was $1.97
- Cash flow from operations was $69 million and free cash flow was $50 million
- The company’s Board of Directors approved an 8% increase in the quarterly cash dividend from $0.65 to $0.70; this equates to an annualized dividend of $2.80 per share
- On June 26, the company released its 2023 Sustainability Report on littelfuse.com/about-us/sustainability
“We are pleased to have exceeded the high end of our second quarter sales and adjusted EPS guidance ranges, driven by solid execution from our global teams and supported by our resilient business model and diverse technology positioning.” said Dave Heinzmann, Littelfuse President and Chief Executive Officer. “Looking ahead, we remain confident in an expected return to growth during 2024, likely in the fourth quarter. We see some pockets of normalized channel inventory and improving end demand but also ongoing signs of cautiousness from customers. We remain well positioned to execute our proven long-term growth strategy and deliver top tier stakeholder value.”
Original – Littelfuse
-
Littelfuse, Inc. announced the launch of the IX4352NE Low-side SiC MOSFET and IGBT Gate Driver. This innovative driver is specifically designed to drive Silicon Carbide (SiC) MOSFETs and high-power Insulated Gate Bipolar Transistors (IGBTs) in industrial applications.
The key differentiator of the IX4352NE lies in its separate 9 A source and sink outputs, which enable tailored turn-on and turn-off timing while minimizing switching losses. An internal negative charge regulator also provides a user-selectable negative gate drive bias for improved dV/dt immunity and faster turn-off. With an operating voltage range (VDD – VSS) of up to 35 V, this driver offers exceptional flexibility and performance.
One of the standout features of the IX4352NE is its internal negative charge pump regulator, which eliminates the need for an external auxiliary power supply or DC/DC converter. This feature is particularly valuable for turning off SiC MOSFETs, saving valuable space typically required for external logic level translator circuitry. The logic input’s compatibility with standard TTL or CMOS logic levels further enhances space-saving capabilities.
The IX4352NE is ideally suited for driving SiC MOSFETs in various industrial applications such as:
- on-board and off-board chargers,
- Power Factor Correction (PFC),
- DC/DC converters,
- motor controllers, and
- industrial power inverters.
It’s superior performance makes it ideal for demanding power electronics applications in the electric vehicle, industrial, alternate energy, smart home, and building automation markets.
With its comprehensive features, the IX4352NE simplifies circuit design and offers a higher level of integration. Built-in protection features such as desaturation detection (DESAT) with soft shutdown sink driver, Under Voltage Lockout (UVLO), and thermal shutdown (TSD) ensure the protection of the power device and the gate driver. The integrated open-drain FAULT output signals a fault condition to the microcontroller, enhancing safety and reliability. Furthermore, the IX4352NE saves valuable PCB space and increases circuit density, contributing to overall system efficiency.
Notable improvements over the existing IX4351NE include:
- A safe DESAT-initiated soft turn-off.
- A thermal shutdown with high threshold accuracy.
- The charge pump’s ability to operate during thermal shutdown.
The new IX4352NE is pin-compatible, allowing for a seamless drop-in replacement in designs that specify the existing Littelfuse IX4351NE, which was released in 2020.
“The IX4352NE extends our broad range of low-side gate drivers with a new 9 A sink/source driver, simplifying the gate drive circuitry needed for SiC MOSFETs,” commented June Zhang, Product Manager, Integrated Circuits Division (SBU) at Littelfuse. “Its various built-in protection features and integrated charge pump provide an adjustable negative gate drive voltage for improved dV/dt immunity and faster turn-off. As a result, it can be used to drive any SiC MOSFET or power IGBT, whether it is a Littelfuse device or any other similar component available on the market.”
Original – Littelfuse
-
Littelfuse, Inc. reported financial results for the first quarter ended March 30, 2024:
- Net sales of $535 million were down 12% versus the prior year period, and down 12% organically
- GAAP diluted EPS was $1.93 and adjusted diluted EPS was $1.76
- Cash flow from operations was $57 million and free cash flow was $42 million
“Our global team delivered solid first quarter results, with sales above and earnings in-line with our expectations, as our increasingly diversified end market exposures, robust technology offering, and portfolio optimization initiatives helped to offset ongoing inventory destocking,” said Dave Heinzmann, Littelfuse President and Chief Executive Officer.
“Further, our strong cash generation reflects disciplined execution, while our well-positioned balance sheet will continue to allow us to capitalize on growth opportunities. Looking forward, we remain confident in an expected return to growth during 2024, and believe our experienced team, agile operations and unwavering long-term strategic focus will drive top-tier value for our stakeholders.”
Second Quarter of 2024*
Based on current market conditions, for the second quarter the company expects,
- Net sales in the range of $525 – $555 million, adjusted diluted EPS in the range of $1.65 – $1.85 and an adjusted effective tax rate of approximately 23%
*Littelfuse provides guidance on a non-GAAP (adjusted) basis. GAAP items excluded from guidance may include the after-tax impact of items including acquisition and integration costs, restructuring, impairment and other charges, certain purchase accounting adjustments, non-operating foreign exchange adjustments and significant and unusual items. These items are uncertain, depend on various factors, and could be material to results computed in accordance with GAAP. Littelfuse is not able to forecast the excluded items in order to provide the most directly comparable GAAP financial measure without unreasonable efforts.
Dividend and Share Repurchase Authorization
- The company’s Board of Directors approved a new stock repurchase authorization to replace its expiring previous 3-year program. The company may repurchase up to $300 million in the aggregate of shares of the company’s common stock for the period May 1, 2024, to April 30, 2027.
- The company will pay a cash dividend on its common stock of $0.65 per share on June 6, 2024, to shareholders of record as of May 23, 2024
Original – Littelfuse
-
Littelfuse, Inc. was recently named one of America’s Most Responsible Companies on Newsweek’s 2024 list. This marks the second consecutive year the Company has been recognized.
This prestigious award is presented by Newsweek and Statista Inc., the world-leading statistics portal and industry ranking provider. The final list recognizes the top 600 most responsible companies in the United States, spanning 14 industries.
“We are proud to be consistently recognized by Newsweek and Statista as one of the most responsible companies in America,” said Dave Heinzmann, Littelfuse President and Chief Executive Officer. “We understand the immense potential to create environmental, social, and ethical impact, and have positioned our business to deliver on our purpose—empowering a sustainable, connected, and safer world. I would like to thank our global teams, customers, suppliers, and partners who work every day to strengthen our sustainability efforts.”
America’s Most Responsible Companies ranking focuses on a holistic view of corporate responsibility that considers all three pillars of ESG: Environment, Social, and Corporate Governance. The analysis is based on KPI research and a public survey.
To learn more about the unwavering commitment of Littelfuse to drive positive change in the world, read the company’s 2022 Sustainability Report at littelfuse.com/about-us/sustainability.Original – Littelfuse
-
Littelfuse, Inc. announced the launch of the FDA117 Optically Isolated Photovoltaic Driver. This innovative product generates a floating power source, making it an exceptional choice for isolated switching applications in a wide range of industries.
The FDA117 is specifically designed to control discrete standard power MOSFETs and IGBTs using a floating voltage source, ensuring isolation between the low-voltage drive input side and high-voltage load output side. With an input control current range of 5 mA to 50 mA, an integrated fast turn-off circuitry, and 5 kVRMS reinforced isolation, the FDA117 provides sufficient voltage and current to drive discrete power MOSFETs and IGBTs effectively.
One of the key differentiators of the FDA117 is its ability to generate a floating power source with up to 15.3 V voltage and 60 µA current, making it suitable for driving standard MOSFET devices and IGBTs. This feature allows for greater flexibility in application designs, enabling the direct driving of standard MOSFET/IGBT devices and securely turning off external power semiconductors in less than 0.5 milliseconds.
Product designs that can benefit from the FDA117 include power semiconductor applications in the following markets (to name a few):
- Industrial
- Energy
- Building Automation
- Smart Home
Whether it is used in custom solid-state relay designs, controlling electrical power and loads, or industrial process control, the FDA117 provides the necessary isolation barrier to protect equipment and individuals from electrical hazards.
“To give our customers more flexibility in their application designs, we developed the FDA117 to add a single-channel version to our existing portfolio of Photovoltaic Drivers,” said Mark P. Smith, Director, Product Management, Integrated Circuits & MCU. “High open circuit voltage and short circuit current, combined with 5 kVRMS reinforced isolation voltage, extend the design flexibility.”
The FDA117 is available in both 4-pin DIP through-hole and surface mount packages, providing pinout compatibility with other Photovoltaic Drivers available on the market. This compatibility ensures ease of integration into existing designs without any major modifications.
The FDA117 Optically Isolated Photovoltaic Driver includes the following key features:
- Operates with as low as 5 mA input control current
- Enables driving standard power MOSFETs and IGBTs
- Provides a floating output voltage ranging from 10.5 V to 15.3 V
- Integrated fast turn-off circuitry for controlled switching
- 5,000 VRMS reinforced insulation for enhanced safety
- 4-pin surface mount and through-hole package options
Original – Littelfuse
